| PERFORMANCE |
| Processor |
Intel® Core Ultra 5 226V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.5GHz, 8MB |
| AI PC Category |
Copilot+ PC |
| NPU |
Integrated Intel® AI Boost, up to 40 TOPS |
| Graphics |
Integrated Intel® Arc™ Graphics 130V |
| Chipset |
Intel® SoC Platform |
| Memory |
16GB Soldered LPDDR5x-8533, MoP Memory |
| Memory Slots |
Memory soldered to systemboard, no slots, dual-channel |
| Max Memory |
16GB soldered memory, not upgradable |
| Storage |
1TB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
| Storage Slot |
One M.2 2242 PCIe® 4.0 x4 slot |
| Max Storage Support |
One drive, up to 1TB M.2 2242 SSD |
| Card Reader |
microSD Card Reader |
| Audio Chip |
SoundWire®, Cirrus Logic® CS42L43 codec |
| Speakers |
4 stereo speakers, 2W x2 (woofers), 2W x2 (tweeters), optimized with Dolby Atmos®, Smart Amplifier (AMP) |
| Microphone |
4x, Array |
| Camera |
5.0MP + IR with E-shutter |
| Battery |
70Wh |
| Power Adapter |
65W USB-C® Slim (2-pin, Wall-mount) |
| DESIGN |
| Display |
14" WUXGA (1920x1200) OLED 600nits (peak) / 400nits (typical) Glossy, 100% DCI-P3, 60Hz, Eyesafe®, Dolby Vision®, DisplayHDR™ True Black 500, X-Rite® |
| Touchscreen |
None |
| Screen-to-Body Ratio |
90% AAR (active area ratio) |
| Color Calibration |
X-Rite® Factory Color Calibration |
| Pen |
Pen Not Supported |
| Keyboard |
Backlit, English |
| Touchpad |
Buttonless glass surface multi-touch touchpad, supports Precision TouchPad (PTP), 80 x 135 mm (3.15 x 5.31 inches) |
| Dimensions (WxDxH) |
312 x 219.3 x 13.9 mm (12.28 x 8.63 x 0.55 inches) |
| Weight |
Starting at 1.19 kg (2.62 lbs) |
| Case Color |
Seashell |
| Case Material |
Aluminium (Top), Aluminium (Bottom) |
| Surface Treatment |
Aluminium Stamping (Anodized with Sandblasting) |
| SOFTWARE |
| Operating System |
Windows® 11 Home, Traditional Chinese / Simplified Chinese / English |
| Bundled Software |
Office Trial |
| CONNECTIVITY |
| WLAN + Bluetooth |
Wi-Fi® 7, 802.11be 2x2 + BT5.4 |
| WWAN |
Non-WWAN |
| Ethernet |
No Onboard Ethernet |
| Standard Ports |
- 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
- 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x microSD card reader
|
| Docking |
Various docking solutions are supported via Thunderbolt™. For more compatible docking solutions, please visit Docking for Yoga® Slim 7 14ILL10 |
| SECURITY & PRIVACY |
| Security Chip |
Firmware TPM 2.0 |
| Fingerprint Reader |
None |
| Other Security |
- Ultrasonic Human Presence Detection
- E-shutter
- IR camera for Windows® Hello (facial recognition)
|
| SERVICE |
| Base Warranty |
1-year, Courier or Carry-in |
| Included Upgrade |
3Y Premium Care -IPPREM (ESS) |
| ACCESSORIES |
| Bundled Accessories |
None |
| CERTIFICATIONS |
| Green Certifications |
- Carbon Neutral Certified
- ENERGY STAR® 8.0
- EPEAT™ Gold Registered
- ErP Lot 6/26
- RoHS compliant
|
| Mil-Spec Test |
MIL-STD-810H military test passed (21 test items) |
| Other Certifications |
- Intel® Evo™ Platform
- Eyesafe® Certified 2.0
- TÜV Rheinland® Flicker Free
- TÜV Rheinland® Low Blue Light (Hardware Solution)
|
