- Product Name
MAG PANO 100R PZ / WHITE
- Case Form Factor
Mid Tower
- Motherboard Form Factor Support
Regular: ATX / Micro-ATX / Mini-ITX
Back-connect: ATX / Micro-ATX
- I/O Ports
1 x USB 20Gbps Type-C
2 x USB 5Gbps Type-A
1 x Audio-Out / Mic-in
1 x LED Switch Button
1 x Power Button
- Drive Mount Support
3 x 2.5”
2 x 2.5”/ 3.5” combo
- Expansion Slots
8
- Maximum GPU Length
400 mm / 15.75 inches
- Maximum CPU Cooler Height
166 mm / 6.54 inches
- Power Supply Support
ATX
- Maximum PSU Length
200 mm / 7.87 inches
- Fan Size Support
Top: 3 x 120 mm / 3 x 140 mm
Front: NA
Rear: 1 x 120 mm
Side: 3 x 120 mm / 2 x 140 mm
Bottom: 3 x 120 mm / 2 x 140 mm / 2 x 160 mm
- Pre-installed Fan Size
Side: 3 x 120 mm
Rear: 1 x 120 mm
- Pre-installed Fan Type
Side: 3 x ARGB Fan (Reverse-blade)
Rear: 1 x ARGB Fan
- Dimensions (DxWxH)
518.7 x 290 x 482 mm / 20.42 x 11.42 x 18.98 inches
- Net Weight
11.30 kg
- Gross Weight
14.2 kg
- Radiator Size Support
Top: 120 / 240 / 360 mm
Front: NA
Rear: 120 mm
Side: 120 / 240 / 360 mm
Bottom: 120 / 240 / 360 mm
Connection
- 1x USB 3.2 Gen 2x2 Type-C
- 2x USB 3.2 Gen 1 Type-A
- Mic In/ Audio Out
- LED Switch Button
- Power Button
產品規格與配備可能會隨地區而有所不同，本公司另保留變更規格不另行通知權利。購買前請與當地經銷商確認產品規格。
