Product NumberNR200PV2-MCNN85-SL0, NR200PV2-MCNN85-SL1
Exterior ColorGrey
Materials - ExteriorSGCC Steel, Mesh, ABS Plastic
Materials - Left Side PanelTempered Glass x1, Steel x1
Dimensions (L x W x H)377 x 185 x 292mm (incl. Protrusions), 360 x 185 x 274mm (excl. Protrusions)
Volume18.25L
Motherboard SupportMini-ITX, Max. size: 170 x 180mm
Expansion Slots3
Drive Bays - 5.25" ODD0
Drive Bays - 3.5" HDD1 (Max. 2, remove bottom fan)
Drive Bays - 3.5" / 2.5" Combo1
Drive Bays - 2.5" SSD1 (Max. 2)
I/O Panel - USB Ports2x USB 3.2 Gen 1 (USB 3.0), 1x USB 3.2 Gen2x2 Type C
I/O Panel - Audio In / Out1x 3.5mm Headset Jack (Audio + Mic)
Included Accessories1x PCIe 4.0 x16 Riser Cable, 1x GPU Holder
Included CPU Cooling Solution2x 140mm SickleFlow PWM, 280mm Radiator, Gen 3 Cooler Master Pump / CPU Block
Included Power Supply UnitV SFX Gold 850W ATX 3.0
Fan Support - Top2 x 120mm / 2 x 140mm
Fan Support - Bottom2 x 120mm (1x max 15mm, w/o 3.5" HDD at the bottom)
Radiator Support - Top120 / 140 / 240 / 280mm
Clearances - CPU Cooler67mm
Clearances - Power Supply130mm
Clearances - Graphics CardExceed front bracket: L: 357.6mm (incl. power connector), H: 160mm (incl. power connector), W: 73mm (triple slot)
Clearances - Graphics CardNot exceed front bracket: L: 334mm (incl. power connector), H: 160mm (incl. power connector), W: 80mm (triple slot)
Dust FiltersBottom, Left, Right, Top Panels
Power Supply SupportSFX, SFX-L
Warranty2 years (Case), 2 years (Thermal Solution), 10 years (Power Delivery)
SizeMini ITX
Exterior ColorGrey
Materials - ExteriorSGCC Steel, Mesh, ABS Plastic
Materials - Left Side PanelTempered Glass x1, Steel x1
Dimensions (L x W x H)377 x 185 x 292mm (incl. Protrusions), 360 x 185 x 274mm (excl. Protrusions)
Volume18.25L
Motherboard SupportMini-ITX, Max. size: 170 x 180mm
Expansion Slots3
Drive Bays - 5.25" ODD0
Drive Bays - 3.5" HDD1 (Max. 2, remove bottom fan)
Drive Bays - 3.5" / 2.5" Combo1
Drive Bays - 2.5" SSD1 (Max. 2)
I/O Panel - USB Ports2x USB 3.2 Gen 1 (USB 3.0), 1x USB 3.2 Gen2x2 Type C
I/O Panel - Audio In / Out1x 3.5mm Headset Jack (Audio + Mic)
Included Accessories1x PCIe 4.0 x16 Riser Cable, 1x GPU Holder
Included CPU Cooling Solution2x 140mm SickleFlow PWM, 280mm Radiator, Gen 3 Cooler Master Pump / CPU Block
Included Power Supply UnitV SFX Gold 850W ATX 3.0
Fan Support - Top2 x 120mm / 2 x 140mm
Fan Support - Bottom2 x 120mm (1x max 15mm, w/o 3.5" HDD at the bottom)
Radiator Support - Top120 / 140 / 240 / 280mm
Clearances - CPU Cooler67mm
Clearances - Power Supply130mm
Clearances - Graphics CardExceed front bracket: L: 357.6mm (incl. power connector), H: 160mm (incl. power connector), W: 73mm (triple slot)
Clearances - Graphics CardNot exceed front bracket: L: 334mm (incl. power connector), H: 160mm (incl. power connector), W: 80mm (triple slot)
Dust FiltersBottom, Left, Right, Top Panels
Power Supply SupportSFX, SFX-L
Warranty2 years (Case), 2 years (Thermal Solution), 10 years (Power Delivery)
SizeMini ITX
