Model Number E301L-KGNN-S00 / E301L-WGNN-S00
Exterior Color Black / White
Materials Steel, Plastic, Tempered Glass (Left Side Panel)
Dimensions (L x W x H)390 x 203.5 x 430mm incl protrusions / 377 x 203.5 x 410mm excl protrusions
Volume 34.13L (incl. Protrusions)
Motherboard Support ITX / Micro ATX
Expansion Slots4
3.5" Drive Bays1
2.5" Drive Bays1 (Max. 2)
I/O Panel1x USB 3.2 Gen 1 Type-A
I/O Panel1x USB 3.2 Gen 1 Type-C
I/O Panel - Audio In / Out1x 3.5mm Combo
Pre-installed Fans - Rear1x 120mm Black Fan
Fan Support - Front3x 120mm
Fan Support - Top2x 120mm / 2x 140mm
Fan Support - Rear1 x 120mm
Radiator Support - Front120 / 240mm
Radiator Support - Top120 / 140 / 240 / 280mm
Radiator Support - Rear120mm
Clearance - CPU Cooler163.5mm
Clearance - PSU160mm
Clearance - GFX365mm (without front fans & radiator)
Cable Routing 18.5mm
Dust Filters Top / Bottom / Front
Power Supply Support ATX
Warranty 2 years
Series Elite Series
SizeMini Tower
