Model Number Q500-DGNN-S00
Exterior Color 3x set: Mint, Pink, Cream
Materials - Exterior Steel, Plastic, TG
Materials - Left Side Panel Grey TG + Steel
Dimensions (L x W x H)406 x 231 x 415mm (Incl. Protrusions)
Dimensions (L x W x H)380 x 231 x 381mm (excl. Protrusions)
Volume33.44L (excl. Protrusions)
Motherboard Support ITX / Micro ATX / ATX / E-ATX (Width up to 296mm w/ SFX PSU, up to 273 w/ ATX PSU)
Expansion Slots7
3.5" Drive BaysMax. 4x 3.5" HDD
2.5" Drive BaysMax. 3x 2.5" SSD
I/O Panel - USB Ports2x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen 2 x 2 Type C
I/O Panel - Audio In / Out1x 3.5mm Combo
Pre-installed Fans - Rear1x 120mm (1800 RPM) SF ARGB White PWM
Fan Support - Front1x 120/140mm (x2 if PSU is mounted in bottom)
Fan Support - Top2x 120/140mm
Fan Support - Rear1x 120mm
Fan Support - Bottom2x 120/140mm
Fan Support - Left side2x 120/140mm
Radiator Support - Front120/140 mm (240/280mm w/ PSU in bottom)
Radiator Support - Top120 / 140 / 240 / 280mm (280mm can be used within 53mm thickness)
Radiator Support - Rear120mm
Radiator Support - Bottom120 / 140 / 240 / 280mm
Radiator Support - Left side120 / 140 / 240 / 280mm
Clearance - CPU Cooler164mm-172mm (Remove the water cooling bracket)
Clearance - PSU173mm to first GPU slot, 216 maximum space (w/o cable management space)
Clearance - PSU332mm space mounted in bottom (w/o cable management space)
Clearance - GFX365mm
Cable Routing - Behind Motherboard Tray 29-32mm
Handle Mint x 1, Grey x 1
Gem Mini Grey x 1
Accessory Hook x 2
Dust Filters Front, Top, Bottom, Right side
Power Supply SupportSFX / SFX-L / ATX
Warranty 2 years
Size Mid Tower
Series QUBE Series
Back Connector Motherboard Support No
