Product Number MLW-D36M-A18PA-R1 (360 Black)
Product Number MLW-D36M-A18PA-RW (360 White)
Product Number MLW-D24M-A18PA-R1 (240 Black)
Product Number MLW-D24M-A18PA-RW (240 White)
Color Black / White
CPU Socket Intel® LGA 1851 / 1700 / 1200 / 1156 / 1155 / 1151 / 1150 Socket
CPU Socket AMD® AM5 / AM4 socket
Radiator Material Aluminum
Radiator Dimensions 394 x 119.2 x 27.2 mm / 15.5 x 4.7 x 1.1 inch (MasterLiquid 360 Core II Black / White)
Radiator Dimensions 277 x 119.2 x 27.2 mm / 10.9 x 4.7 x 1.1 inch (MasterLiquid 240 Core II Black / White)
Radiator Dimensions 157 x 119.2 x 27 mm / 15.5 x 4.7 x 1.1 inch (MasterLiquid 120 Core II Black)
Pump Dimensions 8 3 x 76.2 x 52.3 mm / 3.3 x 3 x 2.1 inch
Pump MTTF >50,000 Hours
Pump Noise Level 25 dBA (Max)
Pump Profiles Addressable RGB
Pump Speed 3100 ± 300 RPM
Pump Connector 3-Pin ARGB + 4-Pin PWM
Pump Rated Voltage 12 VDC
Pump Power Consumption 3.6 W
Fan Dimensions (L x W x H) 120 x 120 x 25 mm / 4.7 x 4.7 x 1.0 inch
Fan Quantity 3 PCS (MasterLiquid 360 Core II Black / White)
Fan Quantity 2 PCS (MasterLiquid 240 Core II Black / White)
Fan Quantity 1 PCS (MasterLiquid 120 Core II)
Fan LED Addressable RGB
Fan Speed 650-1750 RPM ± 10%
Airflow (max.) 120m³/h (70.7CFM)
Fan Noise Level 30 dBA
Fan Air Pressure 2 mmH₂O
Bearing Sleeve Bearings
Fan MTTF >160,000 Hours
Fan Connector 7-Pin PWM + ARGB
Fan Rated Voltage 12 VDC
Fan Rated Current 0.23 A
Fan Safety Current 0.45 A
Fan Power Consumption 2.76 W
Warranty 5 years
Cooler Type Liquid Cooler
Series MasterLiquid Lite
Product Number MLW-D36M-A18PA-RW (360 White)
Product Number MLW-D24M-A18PA-R1 (240 Black)
Product Number MLW-D24M-A18PA-RW (240 White)
Color Black / White
CPU Socket Intel® LGA 1851 / 1700 / 1200 / 1156 / 1155 / 1151 / 1150 Socket
CPU Socket AMD® AM5 / AM4 socket
Radiator Material Aluminum
Radiator Dimensions 394 x 119.2 x 27.2 mm / 15.5 x 4.7 x 1.1 inch (MasterLiquid 360 Core II Black / White)
Radiator Dimensions 277 x 119.2 x 27.2 mm / 10.9 x 4.7 x 1.1 inch (MasterLiquid 240 Core II Black / White)
Radiator Dimensions 157 x 119.2 x 27 mm / 15.5 x 4.7 x 1.1 inch (MasterLiquid 120 Core II Black)
Pump Dimensions 8 3 x 76.2 x 52.3 mm / 3.3 x 3 x 2.1 inch
Pump MTTF >50,000 Hours
Pump Noise Level 25 dBA (Max)
Pump Profiles Addressable RGB
Pump Speed 3100 ± 300 RPM
Pump Connector 3-Pin ARGB + 4-Pin PWM
Pump Rated Voltage 12 VDC
Pump Power Consumption 3.6 W
Fan Dimensions (L x W x H) 120 x 120 x 25 mm / 4.7 x 4.7 x 1.0 inch
Fan Quantity 3 PCS (MasterLiquid 360 Core II Black / White)
Fan Quantity 2 PCS (MasterLiquid 240 Core II Black / White)
Fan Quantity 1 PCS (MasterLiquid 120 Core II)
Fan LED Addressable RGB
Fan Speed 650-1750 RPM ± 10%
Airflow (max.) 120m³/h (70.7CFM)
Fan Noise Level 30 dBA
Fan Air Pressure 2 mmH₂O
Bearing Sleeve Bearings
Fan MTTF >160,000 Hours
Fan Connector 7-Pin PWM + ARGB
Fan Rated Voltage 12 VDC
Fan Rated Current 0.23 A
Fan Safety Current 0.45 A
Fan Power Consumption 2.76 W
Warranty 5 years
Cooler Type Liquid Cooler
Series MasterLiquid Lite
