Bus Type: PCI-E 5.0
Primary Clock Speeds:
Base Clock Up To: 1440 MHz
Game Clock Up To: 2210 MHz
Boost Clock Up to: 2700 MHz
Stream Processors: 4096
Compute Units: 56
Memory Bus: 256bit
Memory Clock: 20 Gbps
Memory Size: 16 GB
Memory Bandwidth: Up to 640 GB/s
Effective Memory Bandwidth: Up to
Memory Type: GDDR6
Card Profile: 3.5 slot
Thermal Solution: 3 Fan
*"Game Clock" is the expected GPU clock when running in typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
**"Boost Clock" is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
Outputs
DisplayPort 2.1: 3x
HDMI™ 2.1: 1x
Requirements
External Power: 2x PCI-E 8 pin connections
Minimum Power Supply Requirement: 800 watt
Certifications
RoHS
Package Contents
Quick Installation Guide: 1
GPU Support Stand: 1
Estimated Dimensions & Weights
Card Dimension (cm) 35 x 14 x 6.7
Card Dimension (inch) 13.98 x 5.51 x 2.64
Master Carton Dimensions (cm) 46 x 39.5 x 47.5
Master Carton Dimensions (inch) 18.11 x 15.55 x 18.7
Master Carton Weight (Kg) 15.3
Master Carton Weight (lb) 33.73
Package Dimensions (cm) 44.5x 23.5 x 12.5
Package Dimensions (inch) 17.51 x 9.25 x 4.92
Package Weight (Kg) 2.35
Package Weight (lb) 5.07
Units/Carton 6
Technologies
64 AMD RDNA™ 4 Compute Units(with RT+AI Accelerators)
AMD Infinity Cache™ technology
DisplayPort™ 2.1
AMD Radiance Display™ Engine
AMD Radeon™ Boost technology*
AMD Radeon™ Anti-Lag* technology*
16GB GDDR6 on 256-Bit Memory Bus
PCI® Express 5.0 ready
AMD FidelityFX™ technologies*
AMD FidelityFX™ Super Resolution technology*
Microsoft® DirectX® 12 Ultimate
Microsoft® DirectStorage
Vulkan® Optimized
AMD smart technologies*
AMD Software: Adrenalin Edition™ application
AMD Noise Suppression*
AMD Privacy View*
AMD Radeon™ Super Resolution technology*
AMD Link*
AMD Freesync™ technology*
Key Features
HDMI™ 4K Support
4K H264 Decode
4K H264 Encode
H265/HEVC Decode
H265/HEVC Encode
AV1 Decode
AV1 Encode
