Product Specifications
Expand All Computing System
Graphics
Storage
I/O Ports
Mechanical
Miscellaneous
Expand All
- Processor
AMD Ryzen™ 9 9850HX (12 Cores, 24 Threads, 3.0 GHz, up to 5.2 GHz) - Chipset
AMD, NVIDIA - System Memory
2 x DDR5-5600 SO-DIMM Memory slots (up to 96GB) (16GB DDR5 SO-DIMM Memory Pre-installed)
- Graphics Engine
ZOTAC GAMING GeForce RTX 5070 12GB GDDR7 - Video Output
1 x HDMI 2.0 (up to 3840x2160@60Hz) (integrated)
3 x DisplayPort 2.1b with UHBR20
(up to 4K 480Hz or 8K 165Hz with DSC)
1 x HDMI® Connector
(Supports 4K 480Hz HDR or 8K 120Hz HDR with DSC, and Gaming VRR as specified in the HDMI 2.1b Specification)
Max 4 displays (cloned) or 6 displays (extended)
- Hard Drive
N/A - Mass Storage
N/A - Optical Drive
N/A - mSATA
N/A - M.2
2 x M.2 NVMe PCIe 5.0 x4 SSD slots (2242, 2280) (1x 1TB M.2 NVMe PCIe 4.0 x4 SSD pre-installed) - Card Reader
3-in-1 (UHS-II SD/SDHC/SDXC)
- Audio
Microphone / Headphone combo port, 8ch via HDMI - USB Port
5 x USB 3.2 Gen 2 (10Gbps, Type-A)
1 x USB 3.2 Gen 2 (10Gbps, Type-C)
2 x USB 3.2 Gen 1 (5Gbps, Type-A)
1 x USB-C ALT Mode (10Gbps) - LAN
5Gbps LAN - Antenna
Dual WiFI SMA connetor - Wifi
WiFi 7 (802.11 be) - Bluetooth
Bluetooth 5.4 - Legacy I/O
N/A - CIR Infrared Port
N/A - Thunderbolt
N/A - USB
N/A - IDE
N/A - VGA
N/A
- Kensington Lock
Yes - LED Indicators
Power, HDD, WiFi - Power Supply
500W 80+ Platinum - Cooling system
Fan + Heatsink - ZBOX Dimensions
270.5mm x 126mm x 249mm (10.65in x 4.96in x 9.8in) - Case Mounting
None
- Supported OS
Windows 11 Home Pre-installed - Accessories
2 x WiFi antenna
Power Cord (bundled cable quantity and type dependent on region)
USB Flash drive with OS Recovery
Warranty Card
Quick Start Guide
