Series
Black Opal：Gaming
Category
Solid State Drives
Model Name
Biwin Black Opal X570H PRO
Form Factor
M.2 2280
Interface
PCIe Gen5×4, NVMe 2.0
DRAM Cache
1 GB
2 GB
4 GB
Capacity
1 TB
2 TB
4 TB
Sequential Read Speed (Up to)
14000 MB/s
14000 MB/s
14000 MB/s
Sequential Write Speed (Up to)
10500 MB/s
13000 MB/s
13000 MB/s
Random Read Speed (Up to)
2000K IOPS
1600K IOPS
2000K IOPS
Random Write Speed (Up to)
1600K IOPS
1600K IOPS
1600K IOPS
Dimensions
80.50 × 23.20 × 9.50 mm (single-sided)
Weight
< 50 g
Operating Temperature
0°C to +70°C
Storage Temperature
-40°C to +85°C
MTBF
1,500,000 hours
Certifications
RoHS, FCC, CE, CB, KCC, BSMI, VCCI, RCM, UKCA
Warranty
5-Year / 750 TBW
5-Year / 1500 TBW
5-Year / 3000 TBW
* 5 years or TBW, whichever comes first.
* Product images shown above are for reference only. For specifics, please refer to the actual product.
* Product packaging, appearance, and additional software may vary due to shipping dates and available inventory.
* Maintenance and future updates are required throughout the product life cycle. Specifications are subject to change without notice.
