Product NameMASTERFRAME 360 STAGE LCD
Model NumberMASTERFRAME 360 STAGE LCD: MF360-KHNN-S02
Color(s)Black
Materials - ExteriorSGCC
Materials - Side panel (Right / Left)TG / TG
Dimensions (L x W x H)549 x 291 x 581 mm (Incl. Protrusions), 511 x 291 x 581 mm (Excl. Protrusions)
Volume86 L (w/o panel, protrusions and feet), 93 L (with panel, protrusions and feet)
Motherboard SupportMini-ITX, Micro-ATX, ATX, BTF (ATX)
Power Supply SupportATX
PCI Expansion Slots3.5
Drive bay support - 3.5" Drive Bays0
Drive bay support - 2.5" / 3.5" Drive Bays (or SSD)1x HDD or 2x SSD
Preinstalled Drive bay - 3.5" Drive Bay (remark Toolfree quantity) / 2.5" Drive Bay(or SSD)(remark Toolfree quantity)1x HDD or 2x SSD
I/O Panel - USB Ports2x USB 3.2 Gen 1 Type-A 5G, 1x USB 4.0 Gen 2x2 Type-C 20G
I/O Panel - Audio In / Out1x 3.5mm Headset Jack (Audio+Mic)
Fan Support - Top6x 120mm, 2x 140mm, 2x 180mm, 2x 200mm
Fan Support - Bottom6x 120mm, 2x 140mm, 2x 180mm, 2x 200mm
Radiator Support - Top120 / 140 / 240 / 280 / 360 mm (maximum thickness clearance 75mm)
Radiator Support - Bottom120 / 140 / 240 / 280 / 360 mm (maximum thickness clearance 75mm)
Dust FiltersMesh Only (Removable Filters)
Other electronic components1x PCI-e 5.0 Riser / 2x ARGB spotlight
Maximum Dimensions for Front Collectibles Display (H x W x D)328 x 290 x 110 mm
DIY tank & Pump supportMASTERFRAME 360 STAGE LCD : Yes (Left side)
ToolboxYes
Clearances - CPU Cooler145 mm
Clearances - Power Supply210 mm
Clearances - Graphics Card430 mm
Cable Routing - Behind Motherboard Tray110 mm
Warranty2 years
SizeMid Tower
SeriesMasterFrame Series
