Model NumberMCS-S400-KN5N-S00 (Steel)
Color(s)Black
Materials - BodySteel, Plastic, Sound Absorbing Material
Dimensions (L x W x H)418 x 210 x 408mm (Incl. Protrusions), 403.5 x 210 x 400mm (Excl. Protrusions)
Volume33.9L (excl. Protrusions)
Motherboard SupportMini-ITX, Micro-ATX
Expansion Slots4
5.25" Drive Bays1
3.5" Drive Bays4
2.5" Drive Bays4
I/O Panel - USB Ports2x USB 3.2 Gen 1 (formerly USB 3.0)
I/O Panel - Audio In / Out1x 3.5mm Headset Jack (Audio+Mic)
I/O Panel - SD Card ReaderSupports SD & MMC Cards
Pre-installed Fans - Front1x 120mm (PWM 800-1400 RPM)
Pre-installed Fans - Rear1x 120mm (PWM 800-1400 RPM)
Fan Support - Front2x 120/140mm
Fan Support - Top1x 120mm, 1x 140mm / 2x 120mm, 2x 140mm (remove ODD cage)
Fan Support - Rear1x 120mm
Radiator Support - Front120 / 140 / 240 / 280mm (remove & reinstall ODD bracket to mount 280mm radiator, may interfere with HDD mounted below ODD bracket)
Radiator Support - Top120 / 240mm* (*240mm requires removal of ODD cage)
Radiator Support - Rear120mm
Clearance - CPU CoolerSteel: 167mm, TG: 166mm
Clearance - PSU325mm (w/o front radiator & drive cage), 140mm (HDD cage in backmost position)
Clearance - GFX319mm
Cable Routing20mm
Dust FiltersFront, Top, Bottom
Power Supply SupportBottom Mount, ATX PS2
SizeMini Tower
SeriesSilencio Series
Color(s)Black
Materials - BodySteel, Plastic, Sound Absorbing Material
Dimensions (L x W x H)418 x 210 x 408mm (Incl. Protrusions), 403.5 x 210 x 400mm (Excl. Protrusions)
Volume33.9L (excl. Protrusions)
Motherboard SupportMini-ITX, Micro-ATX
Expansion Slots4
5.25" Drive Bays1
3.5" Drive Bays4
2.5" Drive Bays4
I/O Panel - USB Ports2x USB 3.2 Gen 1 (formerly USB 3.0)
I/O Panel - Audio In / Out1x 3.5mm Headset Jack (Audio+Mic)
I/O Panel - SD Card ReaderSupports SD & MMC Cards
Pre-installed Fans - Front1x 120mm (PWM 800-1400 RPM)
Pre-installed Fans - Rear1x 120mm (PWM 800-1400 RPM)
Fan Support - Front2x 120/140mm
Fan Support - Top1x 120mm, 1x 140mm / 2x 120mm, 2x 140mm (remove ODD cage)
Fan Support - Rear1x 120mm
Radiator Support - Front120 / 140 / 240 / 280mm (remove & reinstall ODD bracket to mount 280mm radiator, may interfere with HDD mounted below ODD bracket)
Radiator Support - Top120 / 240mm* (*240mm requires removal of ODD cage)
Radiator Support - Rear120mm
Clearance - CPU CoolerSteel: 167mm, TG: 166mm
Clearance - PSU325mm (w/o front radiator & drive cage), 140mm (HDD cage in backmost position)
Clearance - GFX319mm
Cable Routing20mm
Dust FiltersFront, Top, Bottom
Power Supply SupportBottom Mount, ATX PS2
SizeMini Tower
SeriesSilencio Series
