型號
ASUS RT-BE92U
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
WiFi 6E (802.11ax)
WiFi 7 (802.11be)
IPv4
IPv6
Product Segment
BE9700 ultimate BE performance : 1032+2882+5764 Mbps
WiFi Data Rate
WiFi 7 (802.11be) (2.4GHz): up to 1032 Mbps
WiFi 7 (802.11be) (5GHz): up to 2882 Mbps
WiFi 7 (802.11be) (6GHz): up to 5764 Mbps
Antenna
External antenna x 4
Transmit / Receive
2.4GHz 3x3
5GHz 2x2
6GHz 2x2
Processor
2.0GHz quad-core processor
Memory
256 MB Flash and 1 GB DDR4 RAM
Boosts Speed
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
4096-QAM high data rate
20/40/80/160/320 MHz bandwidth
Operating Frequency
2.4 GHz
5 GHz
6 GHz
Operating Mode
Wireless Router Mode
AiMesh Node Mode
Access Point Mode
Media Bridge Mode
Repeater Mode
I/O Ports
1 x 10Gbps for WAN/LAN
1 x 2.5Gbps for WAN/LAN
3 x 2.5 Gbps for LAN
USB 3.2 Gen1 x1
Buttons
WPS Button, Reset Button, Power Switch
LED Indicator
Power x1
WAN x1
LAN x1
2.4GHz x1
5GHz x1
6GHz x1
Power Supply
AC Input: 110V~240V(50~60Hz)
DC Output: 12 V with max. 3 A current
Package Content
RT-BE92U WiFi 7 Tri-band Router
wall mount kit
RJ-45 cable
Power Adapter
Quick Start Guide
Warranty Card
Product Dimensions
247.18 x 101.59 x 287.47 mm / 9.73 x 4.00 x 11.32 inch
AiMesh
有
Parental Control
Web & Apps Filters
Time Scheduling
Safe Browsing
有
• Maximum Parental Control Profile : 64
Guest Network
有
Support Guest Network
• Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 3
Guest Network Pro Encryption : Open system, WPA/WPA2/WPA3-Personal
Security
AiProtection
VPN
WPA/WPA2/WPA3 Personal
WPA/WPA2/WPA3 Enterprise
Open System & OWE
有
DNS-over-TLS
Security Scan
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
AiProtection
AiProtection
有
VPN
Instant Guard
有
Yes
VPN Client WireGuard
VPN Server WireGuard
VPN Fusion
Support Surfshark
Traffic Control
Adaptive QoS
有
-- Maximum Bandwidth Limiter Rule : 32
Traditional QoS
• Traffic Analysis Period : Daily, Weekly, Monthly
WAN
Internet Connection Type :
• PPPoE
• PPTP
• L2TP
• Automatic IP
• Static IP
• IPSec
有
4G / 5G Auto Mobile Tethering
• Maximum Port Forwarding Rule : 64
• Maximum Port Triggering Rule : 32
NAT Passthrough :
• PPTP Pass-Through
• L2TP Pass-Through
• IPSec Pass-Through
• RTSP Pass-Through
• H.323 Pass-Through
• SIP Pass-Through
• PPPoE Relay
LAN
有
• Maximum Manually Assign IP Address Rule : 128
Wireless
MU-MIMO
有
• Maximum MAC Filters : 64
USB application
4G / 5G Auto Mobile Tethering
File System :
• HFS+
• NTFS
• vFAT
• ext2
• ext3
• ext4
有
User Interface
WEB: ASUSWRT
APP: ASUS Router APP
Administration
有
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update
ASUS RT-BE92U
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
WiFi 6E (802.11ax)
WiFi 7 (802.11be)
IPv4
IPv6
Product Segment
BE9700 ultimate BE performance : 1032+2882+5764 Mbps
WiFi Data Rate
WiFi 7 (802.11be) (2.4GHz): up to 1032 Mbps
WiFi 7 (802.11be) (5GHz): up to 2882 Mbps
WiFi 7 (802.11be) (6GHz): up to 5764 Mbps
Antenna
External antenna x 4
Transmit / Receive
2.4GHz 3x3
5GHz 2x2
6GHz 2x2
Processor
2.0GHz quad-core processor
Memory
256 MB Flash and 1 GB DDR4 RAM
Boosts Speed
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
4096-QAM high data rate
20/40/80/160/320 MHz bandwidth
Operating Frequency
2.4 GHz
5 GHz
6 GHz
Operating Mode
Wireless Router Mode
AiMesh Node Mode
Access Point Mode
Media Bridge Mode
Repeater Mode
I/O Ports
1 x 10Gbps for WAN/LAN
1 x 2.5Gbps for WAN/LAN
3 x 2.5 Gbps for LAN
USB 3.2 Gen1 x1
Buttons
WPS Button, Reset Button, Power Switch
LED Indicator
Power x1
WAN x1
LAN x1
2.4GHz x1
5GHz x1
6GHz x1
Power Supply
AC Input: 110V~240V(50~60Hz)
DC Output: 12 V with max. 3 A current
Package Content
RT-BE92U WiFi 7 Tri-band Router
wall mount kit
RJ-45 cable
Power Adapter
Quick Start Guide
Warranty Card
Product Dimensions
247.18 x 101.59 x 287.47 mm / 9.73 x 4.00 x 11.32 inch
AiMesh
有
Parental Control
Web & Apps Filters
Time Scheduling
Safe Browsing
有
• Maximum Parental Control Profile : 64
Guest Network
有
Support Guest Network
• Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 3
Guest Network Pro Encryption : Open system, WPA/WPA2/WPA3-Personal
Security
AiProtection
VPN
WPA/WPA2/WPA3 Personal
WPA/WPA2/WPA3 Enterprise
Open System & OWE
有
DNS-over-TLS
Security Scan
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
AiProtection
AiProtection
有
VPN
Instant Guard
有
Yes
VPN Client WireGuard
VPN Server WireGuard
VPN Fusion
Support Surfshark
Traffic Control
Adaptive QoS
有
-- Maximum Bandwidth Limiter Rule : 32
Traditional QoS
• Traffic Analysis Period : Daily, Weekly, Monthly
WAN
Internet Connection Type :
• PPPoE
• PPTP
• L2TP
• Automatic IP
• Static IP
• IPSec
有
4G / 5G Auto Mobile Tethering
• Maximum Port Forwarding Rule : 64
• Maximum Port Triggering Rule : 32
NAT Passthrough :
• PPTP Pass-Through
• L2TP Pass-Through
• IPSec Pass-Through
• RTSP Pass-Through
• H.323 Pass-Through
• SIP Pass-Through
• PPPoE Relay
LAN
有
• Maximum Manually Assign IP Address Rule : 128
Wireless
MU-MIMO
有
• Maximum MAC Filters : 64
USB application
4G / 5G Auto Mobile Tethering
File System :
• HFS+
• NTFS
• vFAT
• ext2
• ext3
• ext4
有
User Interface
WEB: ASUSWRT
APP: ASUS Router APP
Administration
有
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update
- 經FCC和加拿大工業部認證的產品將在美國和加拿大銷售。請參閱華碩美國和華碩加拿大網站，瞭解有關當地可用產品的資訊。
- 所有規格如有更改，恕不另行通知。請與您的供應商/經銷商確認確切的報價。產品可能並非在所有市場都可用。
- 規格和功能或內建軟體因型號而異，所有圖像僅供參考。有關完整詳細資訊，請參閱規格頁面。
- 產品顏色可能會因拍照光線誤差或螢幕設定而與實際產品有所差異。
- 商標聲明：本網站所談論到的產品名稱僅做識別之用，而這些名稱可能是屬於其他公司的註冊商標或是版權。
- HDMI、HDMI高畫質多媒體介面及HDMI 標誌為HDMI Licensing Administrator, Inc.在美國及其他國家的商標或註冊商標。
- The actual transfer speed of USB 3.0, 3.1, 3.2, and/or Type-C will vary depending on many factors including the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment.
- Actual data throughput and WiFi coverage will vary from network conditions and environmental factors, including the volume of network traffic, building material and construction, and network overhead, result in lower actual data throughput and wireless coverage.
- Quoted network speeds and bandwidth based on current IEEE 802.11ac specifications. Actual performance may be affected by network and service provider factors, interface type, and other conditions. Connected devices must be 802.11ac-compatible for best results.
