• 料號編碼
• EdgeXpert MS-C931

System Processor

• CPU
• 20 core ARM, 10 Cortex-X925 + 10 Cortex-A725 ARM

• Frequency
• --

• L2 Cache
• --

• CPU Type
• onboard

• Chipset
• onboard

• BIOS
• --

• Tensor Performance
• 1 petaFLOP Al Performance (FP4, Sparse)

Memory

• Technology
• LPDDR5x

• Max. Capacity
• 128GB

• Socket
• onboard

Graphic

• Controller
• Nvidia^® GB10

• Graphic Memory
• Share 128GB unified Memory

• Multiple Display
• 4 independent displays

• Display Interface
• HDMI 2.1, 4x DP1.4a via USB-C

Ethernet

• Controller
• 1 x 10GbE

Audio

• Controller
• --

H/W Monitor

• Watchdog Timer
• --

• Smart Fan
• Yes

TPM

• Controller
• Y

I/O Interface

• PS/2
• --

• CANbus
• --

• LVDS
• --

• VGA
• --

• RJ-45
• 1

• PoE
• --

• Audio
• HDMI Multichannel Audio output

• USB
• 4 x USB 3.2 Type-C

• Parallel
• --

• Serial
• --

• HDMI
• 1

• GPIO
• --

• DVI
• --

• DisplayPort
• 3 via USB-C

• Antenna
• 2

• QSFP
• 2

• WiFi
• WiFi 7*
  * Wi-Fi 7 functionality depends on local regulatory approval. Restricted bands will be activated via software updates once legal requirements are met in the region.

• Bluetooth
• BT 5.4

Expansion Slot

• PCIe x16
• --

• PCIe x8
• --

• PCIe x4
• --

• PCIe x1
• --

• PCI
• --

• M.2
• 1x M.2 M Key 1TB/4TB SSD with self-encryption

• Mini-PCIe
• --

Storage

• SATA
• --

• CFast
• --

• mSATA
• --

• CompactFlash
• --

Power Supply

• DC Input
• ~240W USB-C with external power adapter

• AC Input
• --

Environment

• IP Rating
• --

• Operating Temperature
• 0 ~ 35°C

• Operating Humidity
• 10 ~ 90%, non-condensing

• Storage Humidity
• 10 ~ 90%, non-condensing

• Storage Temperature
• 0 ~ 60°C

• Vibration
• --

• Shock
• --

Physical Characteristics

• Dimensions
• 151 x 151 x 52 mm

• Weight
• 1.2 kg

• Mounting
• --

Certification

• EMC
• FCC Class B, CE, UKCA, VCCI, BSMI

• Safety
• BSMI

Software Platform

• OS Support
• NVIDIA DGX™ OS

NIC

• Controller
• ConnectX-7 NIC @200 Gbps

• 原裝行貨
• 1年代理保養
