Baseus USB Type C HUB Multi-function Adaptor USB C Hub Docking Station for Macbook Pro USB 3.0 HUB Splitter Computer Accessories

- 16 Ports:

Type-C PD*1; USB2.0*2; VGA*1; 4K HD*1; DC powder supply*1;

RJ45*1; SD/TF*1; USB3.0*3; Type-C*2; 3.5mm audio jack*1

Item:

- 16 Ports:

Type-C PD*1; USB2.0*2; VGA*1; 4K HD*1; DC powder supply*1;

RJ45*1; SD/TF*1; USB3.0*3; Type-C*2; 3.5mm audio jack*1

- 17 Ports:

3.5mm audio jack*1; USB-C*2; USB3.0*3; SD*1; TF*1; RJ45*1

DC12V*1; 4K HD*3; USB2.0*2; PD*1; PC*1

Note: Picture quality is 1080P when 4K HD and VGA are used simultaneously

Parameters:

-Type-C PD input: 100W

-4KHD: Supports 4K@30Hz HD display

-USB3.0*3:Transmission rate 5Gbps, downward compatible with USB2.0 and USB1.1

-USB2.0*2:Transmission rate 480Mbps, downward compatible with USB1.1

-SD/TF:Maximun 2T data reading is supported(simultaneous reading not supported, card inserted first is preferentially read)

-3.5mm audio jack:Supports input and output

-Type-C*2:Supports reading from Type-C Flash disk(Type-C audio output not supported),

Max Only supports 7.5W single-port output.

-HUB static power comsumption:2W

-Working current:450~2550mA

-Operating temperature:0~45℃

-Storage temperature:-10℃ ~+70℃

Notes:

1. Ensure that your laptop’s USB-C port supports PD Power Delivery, DP Alt Mode and Data Transfer. Otherwise, some interface functions of the docking station can‘t be used. Consult your laptop’s manual or contact the manufacturer for this information.(The Laptop has thunderbolt 3 / USB-C 3.1 Gen 2 / USB-C 3.2 Gen 2 port support power deliver, hdmi output and 10Gb/s data transfer. The USB-C 3.1 Gen 1 port: 5Gb/s (data transfer only) can't support hdmi display.)

2. To ensure a stable casting or mirroring experience, use the same model of monitor as connecting to 3 different screen display may cause your laptop to misread monitors information and may result into displaying content abnormally.

3. This docking station supports up to 4K@30Hz. The final output depends on the maximum output resolution supported by your laptop’s graphic card and screen display you use.

4. Not Compatible with Huawei matebookd15 / Lenovo Yoga 6 / Lenovo ideapad 320s / Ideapad S145-15IWL / Lenovo e590 / Acer Nitro 5 AN515 / Acer Aspire 5 a515-44-r1bu

New Upgrade 16 Ports:

Compatible with Mac OS/ Windows Systems and able to expand to four large screens simultane-ously. extend mode/ mirror mode display at any time, displaying different content in multi-screen mode.

*Multi-interface,upgraded 17-in-1 design

*Fast transfer,5Gbps read and write speed

*3 4K HD ports,different content display in split-screen projection

*HIgh power,100W PD input

Powerful Chip,Extraordinary Help

Built-in genuine VL 817 master chip ensures the normal operation of 17 interfaces.Faster speed and higher office efficiency

More Efficient Office with Three Different Screens

Supports the simultaneous use of 3 4K HD ports and different content display in split-screen projection

Not Enough Interfaces Relieve from 5 Interfaces

Self-contained 5 USB interfaces can meet the needs of multiple devices at the same time. And USB 3.0 transmission speed up to 5Gbps,which can drive two 4T hard drives at the same time

2T Rapid Reading and Editing without Delay

TF/SD dual-card reading is designed to meet the needs of photographers and video editors.Fast reading without affecting office efficiency

Enjoy Efficient Office work with Stable Network Speed

Support 1000Mbps network speed,download and transmission can be completed in minutes

100W PD Input Faster Power Storage from Computer

Expanding an additional power supply port for your computer to avoid power outages in your office.Support PD 100W(Max)high-power dash charging

Two-way transmission without Delay

Dual USB-C interface can be used for data transmission and qucik charging for devices Output power up to 7.5W Max

Interface Extension Enjoy Music and Never Stop

3.5mm interface is resvered so that user can use without buying additional adapters

Power Provided 17 ports Operated

When 17 ports are running at the same time, the insufficient power supplied by the computer to the HUB will easily cause the HUB operation failure.It is recommended to use with the power supply
