QGeeM USB C Hub for Macbook Pro Air HDMI VGA Micro SD Card Readers RJ45 Aux PD OTG Multi USB Hub Type C 3.0 Adapter for Notebook

FEATURE

1.USB-A 3.0 Ports: 5Gbps Data Transfer

2.USB-C 3.0 Ports: 100W PD Charger

3.HDMI Ports: 4K Video Output

4.RJ45 Port: 1000Mbps Gigabit Lan Network

5.SD/TF Port: Support SD/TF Reading to Max 2TB

6.AUX Port: Support Headphone & Microphone

7.Cool LED Indicator; Compact & Portable

8.Input Port: USB 3.1 Gen2 10Gbps

9.Space Grey Alu-Alloy Shell as MacBook

10.Widely Compatible for Macbook Pro, Surface Pro 6, Huawei Matebook

Compatible Devices

Mac Book Pro, Xiaomi, Samsung, Dell, Asus, Huawei, Lenovo, Google,
Samsung S8/S8+/S9/S9+/S10/S10+, Huawei Mate 10/20/P20/P30
Such as computers and mobile phones with standard TYPE-C ports.

Support Systems

Google Chrome OS; Windows 7/8/10; XP; Linus; Vista; Plug and Play, notebooks that support the standard Type-C interface and PD charging protocol.

1. Product Introduce:

This product is a high-performance TYPE-C to USB3.0 hub and a multifunctional product with a video output interface.
Through this product, it can provide USB-A 3.0 2.0and USB-C 3.0 external interfaces for computers with TYPE-C interface, and connect the HDMI cable to high-definition monitor.
It can support 3840x2160 @ 30Hz high-definition video output.
It is a stylish appearance hub for those TYPE-C computers, mobiles and tablets.

2.Operation Introduce

1)Connect the computer to the USB3.1 TYPE-C connector of this hub
2)Use the HDMI male connector to connect the HDMI female socket of this hub, and then to the projector, TV, monitor, etc
3)Connect a USB device to the USB port of this hub

3.Attention

1)Because USB3.0 standard current is 1A, if the current output of new Macbook is about 1A, when the computer load exceeds 1A, the computer will start the self-protection function and prompt: USB power consumption is large, disable.
At this time, you need to unplug the hub, close the disable icon or restart the machine, and then check for new connection devices.

2)If a device with a large power consumption such as a hard disk is connected, when it cannot be connected and used normally, please unplug the other U disk device so that the USB device with large power can normally supply power.

3)The load current varies greatly between different devices. The following reference currents are provided for related devices.
USB mobile hard drive: 550mAh / 1.5A
U disk: 200mAh / 350mAh
Mouse: 100mAh, gaming mouse up to 350mAh;
SD card: 150mAh-300mAh
HDMI: 350mAh

4)Computer load protection current is 1.5A. Computer load protection will cause interruption or abnormal operation of external equipment.

In order to ensure that the current load exceeding 1.5A can work normally, the product can only load one USB mobile hard disk, and it is not suitable to insert two high-current USB devices at the same time.

5)This product is designed according to the real-time USB3.1 standard specification. It may not be compatible with products or devices that exceed the standard specification after the product is manufactured, which is normal.
This product is a high-performance TYPE-C to USB3.0 hub and a multifunctional product
